樹脂夾織物導向帶-James walker Lionsele B2 bearing strip
This plain rectangular strip of synthetic fabric impregnated with thermosetting
resin provides a cost-effective and easyto- use alternative to traditional materials
such as phosphor bronze or lead.
Special features
Self-lubricating to provide low dynamic and breakout friction.
High resistance to wear.
Suitable for heavy-duty applications.
High strength material that offers long life and damping of mechanical vibrations to reduce plant downtime.
Versatile and easy to assemble.
Typical applications
Often used in conjunction with compacttype piston head seals in hydraulic systems to eliminate metal-to-metal contact and other problems associated with offset pistons.
Operating capabilities
Maximum bearing stress at RT (static duty): 400MPa (58,015psi).
Maximum bearing stress at RT (dynamic duty): 90MPa (13,053psi).
Temperature range: -60°C to +100°C (-76°F to +212°F); or +130°C (+266°F)
with severely restricted load carrying capacity on dynamic duties.
aximum recommended relative
velocity: 1.0m/s (196.9fpm).
Materials of construction
Synthetic fabric impregnated with thermosetting resin.
Tape thickness
Tape thickness varies according to tape width. Note that thin strip dissipates heat
more efficiently and therefore the thermal expansion will be less.
Bearing strip cutting
The standard type of cut is 45° scarf split. Other types of cut are available
on request.
